KVM Switch - Dual-Monitor, DisplayPort 1.2, 4K 60Hz, USB 3.0 Hub, Audio
Photo may vary from actual product
KVM Switch - Dual-Monitor, DisplayPort 1.2, 4K 60Hz, USB 3.0 Hub, Audio
KVM Switch - Dual-Monitor, DisplayPort 1.2, 4K 60Hz, USB 3.0 Hub, Audio


KVM Switch - Dual-Monitor, DisplayPort 1.2, 4K 60Hz, USB 3.0 Hub, Audio

KV6224DP



Access 4K dual-monitor DisplayPort computers and shared USB 3.0 peripherals from a single workstation


  • Maximum productivity with 4K dual-display, multi-computer access
  • Crystal-clear picture quality with support for Ultra HD 4K resolutions at 60Hz
  • Share your USB peripheral devices with built-in 2-port USB 3.0 Gen1 (5Gbps)
  • Full Independent multimedia control with separate 3.5 mm audio support
  • Supports advanced keyboards and mice


KV6224DP Properties

  • 4 ports
  • (2) DisplayPort 1.2
  • USB 3.0 Hub, Audio
  • KV6220 Series
KV6224DP (4 ports, (2) DisplayPort 1.2, USB 3.0 Hub, Audio, KV6220 Series)
Unit price
On request
Dual 4K Monitor Support
Share two 4K monitors between DisplayPort 1.2 enabled computers; using only one keyboard and mouse saving valuable desk space and increasing productivity.

Ultra HD 4K60 Resolution
DisplayPort 1.2 Technology delivers crystal-clear 4K at 60Hz Ultra HD resolution driving two large external 4K (DisplayPort enabled) monitors.

Advanced Keyboards and Mice
Support for advanced keyboards and mice. Emulation technology allows complete versatility in dealing with the advanced functional requirements of today’s keyboards and mice. From gaming mice/keyboards to advanced business mice/keyboards, users will appreciate what this technology can do for them.

Peripheral Sharing
Share all your USB 3.0 devices with ease with the separate built-in 2-port USB 3.0 Gen1 (5Gbps). This allows the sharing of USB peripherals between each connected computer. Automatically switch connected USB devices to the selected computer.

Total Multimedia Control
Individual audio (mic/speaker) channels let you share independent audio from each of the connected computers allowing complete multimedia control between the different computers.

Product variants

  Product       Code
2 port
(2) DisplayPort 1.2

USB 3.0 Hub, Audio
  KVM Switch - Dual-Monitor, DisplayPort 1.2, 4K 60Hz, USB 3.0 Hub, Audio
KVM Switch - Dual-Monitor, DisplayPort 1.2, 4K 60Hz, USB 3.0 Hub, Audio
  KV6222DP
4 ports
(2) DisplayPort 1.2

USB 3.0 Hub, Audio
  KVM Switch - Dual-Monitor, DisplayPort 1.2, 4K 60Hz, USB 3.0 Hub, Audio
KVM Switch - Dual-Monitor, DisplayPort 1.2, 4K 60Hz, USB 3.0 Hub, Audio
  KV6224DP
These KVM Switches replace KV6222A-R2 and KV6224A-R2
