Hardened Gigabit PoE+ 8-Port Switch
Photo may vary from actual product
Hardened Gigabit PoE+ 8-Port Switch
LPH008A-R2: -40 to +75° C, (8) RJ45 PoE+, Dual 12-57 VDC
LPH008A-R2: -40 to +75° C, (8) RJ45 PoE+, Dual 12-57 VDC


Hardened Gigabit PoE+ 8-Port Switch


Deliver PoE+ power to eight remote PDs, such as cameras, access points, phones and more.


  • Provides eight PoE+ PSE 10/100/1000-Mbps RJ-45 ports
  • PoE+ 802.3at compliant, provides up to 30 watts per port with a total power budget of 60 watts at 12-24VDC and 120 watts at 24-57 VDC.
  • Power remote PoE+ PDs such as security cameras, wireless access points, traffic control equipment, monitoring devices, and more.
  • Use in industrial applications, such as oil/gas fields, utilities, security/surveillance, SCADA/M2M, and building automation.
  • Eliminates worries about powering distant equipment where no power is available.
  • Rated for extreme temperatures of -40 to +75° C.
  • IP30 enclosure for use in harsh INDOOR OR OUTDOOR environments.
  • Dual 12-57-VDC DC power inputs for redundant power.
  • Generates 50 VDC PSE power output per port.
  • Supports jumbo frames up to 9K bytes.
  • Autonegotiation, auto MDI/MDI-X.
  • DIN-rail mounted.
  • Warranty: 5 Year Double Diamond™ Warranty (Standard)

  Product       Code
-40 to +75° C
(8) RJ45 PoE+

Dual 12-57 VDC
  Hardened Gigabit PoE+ 8-Port Switch
Hardened Gigabit PoE+ 8-Port Switch
  LPH008A-R2

Accessories

  Product     Code

  DIN Rail Power Supplies - 24VDC, 120w
DIN Rail Power Supplies
  SDR-120-24

Two different power inputs at the terminal block prevent the power interruptions. When the primary DC power input fails, the backup power input takes over to guarantee non-stop operation.
