HDMI 2.0 4K Video Switch - 3x1 / 4X1


Cost-effective, compact, easy-to-install switch for reliable switching of 4K HDMI signals between three or four sources and one display.


  • 3 or 4-to-1 HDMI switching for UHD video
  • Fully compliant with HDMI 2.0 and HDCP 2.2
  • HDMI inputs and output support resolutions up to 4K @ 60 Hz 4:4:4 8-bit
  • Supports top panel button, IR remote, and automatic switch control options
  • Compact size
  • Supports locking HDMI cables to prevent accidental cable disconnections
  • CE, FCC, IC, RCM, and VCCI approvals

  Product       Code


3 to 1
  HDMI 2.0 4K Video Switch - 3x1 / 4X1
HDMI 2.0 4K Video Switch - 3x1 / 4X1
  VSW-HDMI2-3X1

4 to 1
  HDMI 2.0 4K Video Switch - 3x1 / 4X1
HDMI 2.0 4K Video Switch - 3x1 / 4X1
  VSW-HDMI2-4X1

Accessories

  Product     Code

  Premium High-Speed HDMI Cable with Ethernet and Gripping Connectors – HDMI 2.0, 4K 60Hz UHD, 3-ft. (0.9-m) - Video Cable, HDMI 2.0, M/M, 0.9m
Premium High-Speed HDMI Cable with Ethernet and Gripping Connectors – HDMI 2.0, 4K 60Hz UHD, 3-ft. (0.9-m)
  VCB-HD2L-003
  Premium High-Speed HDMI Cable with Ethernet and Gripping Connectors – HDMI 2.0, 4K 60Hz UHD, 6-ft. (1.8-m) - Video Cable, HDMI 2.0, M/M, 1.8m
Premium High-Speed HDMI Cable with Ethernet and Gripping Connectors – HDMI 2.0, 4K 60Hz UHD, 6-ft. (1.8-m)
  VCB-HD2L-006
  Premium High-Speed HDMI Cable with Ethernet and Gripping Connectors – HDMI 2.0, 4K 60Hz UHD, 10-ft. (3.0-m) - Video Cable, HDMI 2.0, M/M, 3m
Premium High-Speed HDMI Cable with Ethernet and Gripping Connectors – HDMI 2.0, 4K 60Hz UHD, 10-ft. (3.0-m)
  VCB-HD2L-010
  HDMI Splitter, HDMI 2.0 4K60, 1x2 or 1x4 - 2 Channel
HDMI Splitter, HDMI 2.0 4K60, 1x2 or 1x4
  VSP-HDMI2-1X2
  HDMI Splitter, HDMI 2.0 4K60, 1x2 or 1x4 - 4 Channel
HDMI Splitter, HDMI 2.0 4K60, 1x2 or 1x4
  VSP-HDMI2-1X4

Switching between three HDMI sources to a single display is easier and more reliable. The HDMI 2.0 Video Switch - 4K60, HDCP, 3x1 features HDMI 2.0 and HDCP 2.2 compatibility and supports resolutions up to 4K @ 60 Hz 4:4:4 8-bit, enabling three Ultra HD sources to be switched to one Ultra HD display. It also allows control through a top panel button, IR remote and automatic switch. The switch is small, compact and easy to install, giving you the convenience of future-ready Ultra HD AV switching, and the reliability of cutting-edge HDMI 2.0 and HDCP 2.2 compatibility

With increased bandwidth up to 18 Gbps, you can switch signals from three or four sources to a single display while maintaining:
  • Higher resolutions
  • Higher frame rates
  • Multiple full HD streams in the same pipe
  • 21:9 aspect ratio
